₨ 10,000
| SKU | Description | Ampere Ratings | Sensitivity | Price | Quantity | |
|---|---|---|---|---|---|---|
| NL1-63-11 | RCCB, NL1-63, 4P, 30ma | 25 Amps | 30mA | ₨ 10,000 | ||
| NL1-63-12 | RCCB, NL1-63, 4P, 300ma | 25 Amps | 300mA | ₨ 10,000 | ||
| NL1-63-13 | RCCB, NL1-63, 4P, 30ma | 40 Amps | 30mA | ₨ 10,000 | ||
| NL1-63-14 | RCCB, NL1-63, 4P, 300ma | 40 Amps | 300mA | ₨ 10,000 | ||
| NL1-63-15 | RCCB, NL1-63, 4P, 30ma | 63 Amps | 30mA | ₨ 10,000 | ||
| NL1-63-16 | RCCB, NL1-63, 4P, 300ma | 63 Amps | 300mA | ₨ 10,000 |
Best Price | Reliable Protection | Premium Quality
The CHINT NL1-63 Residual Current Circuit Breaker (RCCB) is designed to detect earth-leakage currents and disconnect the electrical supply when residual current exceeds the specified operating threshold. It helps reduce the risk of electric shock and electrical fires caused by earth-leakage faults.
The four-pole configuration is suitable for compatible three-phase, four-wire electrical distribution systems. The NL1-63 range offers different rated-current and residual-current sensitivity options for residential, commercial, and industrial applications.
Available sensitivity options include 30mA and 300mA. These are separate product variants and must be selected according to the intended protection requirement.
Important: An RCCB provides residual-current protection only. It does not provide overload or short-circuit protection by itself and must be coordinated with suitable overcurrent protection.
| Parameter | Specification |
|---|---|
| Brand | CHINT |
| Product series | NL1-63 |
| Product category | Residual Current Circuit Breaker (RCCB) |
| Product type | Residual-current protection device without integrated overcurrent protection |
| Number of poles | 4P |
| Intended system | Three-phase, four-wire system |
| Rated current (In) | Available variants include 25A, 40A and 63A; select the required rating |
| Rated residual operating current (IΔn) | 30mA or 300mA, depending on the selected variant |
| Rated operational voltage (Ue) | 400V AC for the four-pole version; regional documentation also lists 415V |
| Rated frequency | 50/60Hz |
| Residual-current detection type | Type AC or Type A, depending on the exact product suffix |
| Overload protection | Not integrated |
| Short-circuit protection | Not integrated; suitable upstream/downstream protective coordination required |
| Standard | IEC/EN 61008-1 |
| Rated insulation voltage (Ui) | 500V for applicable 25A/40A/63A versions; confirm exact variant |
| Rated impulse withstand voltage (Uimp) | 4kV, as listed in product documentation |
| Rated residual making and breaking capacity (IΔm) | 500A for applicable ratings up to 40A; 630A for 63A versions |
| Rated conditional short-circuit current | Depends on the exact version and specified backup protective device; verify the applicable datasheet |
| Typical disconnection time | Less than 0.1 seconds for the normal, non-delayed version under specified test conditions |
| Protection degree | IP20, subject to correct installation |
| Mounting | 35mm DIN rail, according to EN 60715 |
| Connection | Top and bottom terminals |
| Terminal connection | Compatible cable or busbar, subject to terminal specifications |
| Ambient operating temperature | −25°C to +40°C, subject to manufacturer’s conditions |
| Pollution degree | 2 |
| Installation category | Class II and III, as specified in the applicable manual |
| Application | Earth-leakage protection in low-voltage AC distribution systems |
Specification note: These are range-level and model-family specifications based on CHINT documentation. Confirm the exact rated current, Type AC/Type A classification, short-circuit coordination, and product code before publishing a particular SKU or submitting it for project approval.
The 30mA version is intended for applications requiring high-sensitivity residual-current protection, including supplementary protection against electric shock where required by the applicable electrical code.
Typical applications include:
The 300mA version is generally used where residual-current protection is required at a distribution or feeder level, including certain fire-risk protection strategies.
Typical applications include:
Selection advice: A 300mA RCCB is not a substitute for 30mA supplementary protection where the latter is required. For installations using both levels, check discrimination and selectivity between the devices. A time-delayed selective
In the intricate realm of electrical systems, safety isn’t just an option—it’s the number one priority. You might already know about basic circuit breakers, but let me introduce you to the NL1-63 4P 30mA/300mA, a true game-changer. This isn’t just another safety gadget; it’s a multifunctional, all-in-one solution crafted for professional use in tough environments. What sets this residual current circuit breaker apart is its dual-sensitivity protection, which lets you toggle between 30mA for personal safety and 300mA for serious fire prevention.
So, what does this mean for your electrical project? It translates to unmatched flexibility and control. Whether you’re protecting a commercial building, an industrial workshop, or a complex three-phase system, this single device delivers the right level of protection for any scenario. In this detailed guide, we’ll dive into the technology behind the NL1-63 4P 30mA/300mA, highlight its key features, and show you how to harness its capabilities for maximum security.
The NL1-63 is a four-pole Residual Current Circuit Breaker (RCCB) that’s specifically designed for low-voltage electrical distribution. Its job is straightforward yet crucial: it helps prevent electric shocks and fire hazards that can occur due to current leakage.
This RCCB is suitable for a wide range of environments:
You may also like:
NL1-63 2 Pole RCCB (30 mA & 300 mA) – Ultimate Safety Choice
Compliant Standards: VITS61008-
1 Control electric circuits.
Protect people against indirect contacts and provide additional protection against direct contacts.
Protect installations against fire hazards due to insulation faults.
